Nature Power 30 Amp Charge controller - Nature Power
In Stock & Ready to Ship
All orders are shipped within 1-2 business days. Product ETA 7-14 business days.
Any solar panel that is rated 12 watts or higher requires the use of a solar charge controller to regulate the current and voltage going to the battery. This 30 Amp Charge controller can handle up to 450 Watts of Solar array. It will automatically recognize if you are using a 12v or 24v system. Download the APP ChargePro for mobile phone monitoring and operation. Solar charge controllers are for permanent installation and should be installed close to the battery in a dry and ventilated area.
ChargePro App on IOS or Google Play
Pre set charging modes available for most common battery types
Specifications
- Charge Controller Type: Pulse Width Modulation (PWM)
- DC Input
- Max solar Input Voltage : <55V
- Input Current: 30A(Max)
- Solar Panel Rating (Max): 12V/450W 24V/900W
- Charge Controller Output to Battery
- Battery Rating: 12V / 24V (Auto Detect)
- Battery Type: SEL / GEL / FLD / Li / Use
- Charge Voltage Range: 9~15V, Default:14.2V
- Float Voltage Range: 9~15V, Default:13.8V
- DC Load
- DC Load Current: 30A (Max)
- PROTECTION:
- PV Reverse Polarity: Protected
- Boost Charge Recovery voltage: 13.2V
- Over-Discharge Recovery Voltage: 12.6V
INCLUDED:
Warranty
1 year Limited Warranty
